Retired

APSX Plastic Injection Molding Machine Manufacturer: APSX Model: APSX PIM Specifications: 30 cu-cm injection volume. 345 BAR injection pressure. 5 tons clamping force. 4.8"x6" mold size. Opening stroke w/ & w/o ejector plate 5.5-7" Applications: Low rate production, in-house, injection injection molding. Compatible with 3D printed molds made from high temperature resistant materials like FormLabs High Temp Resin, MarkForged Onyx or Stratasys PolyJet.

Nikon Metrology XTH160 Micro CT Manufacturer: Nikon Metrology Model: XT H 160 Specifications: 30-160 kV X-rays, 3 micron focal spot size, 5-axis manipulator, video radiography, accelerated 3D reconstruction Applications: Real-time 2D X-ray imaging and 3D volumetric imaging for process metrology, experimental sample characterization, rapid-prototyping input, and reverse-engineering

Universal Laser Cutter Manufacturer: Universal Laser Systems Model: X2-600 Specifications: 100W CO2 Working area 813 x 457 mm (32in. x 18in.) Applications: Cutting of cardboard, paper and thin plastics

Kalamazoo Horizontal Band Saw Manufacturer: Kalamazoo Saws Model: Horizontal Band Saw Specifications: 4 speed step pulley with worm gear speed reducer, Heavy-duty hydraulic cylinder with precision ground hinge support, Cast iron bed, Adjustable stock stop, Easy blade change with front access at Applications: Cutting metal stock

Dimension Elite 3D Printer Manufacturer: Stratasys Model: Dimension Elite Specifications: Model material - ABSplus. Support material - Soluble Support Technology (SST). Build Size - 203 x 203 x 305 mm (8 x 8 x 12 in.) Applications: Fusion Deposition Modeling (FDM) 3D printing

Large Format 5 Axis Milling Machine Manufacturer: ShopBot Model: 5-axis Specifications: Work area 82in. X (864mm) x 34in. Y (864mm) x 24in. Z (610mm), Step resolution of .0004in., Positional accuracy of +/- .002in. Applications: Milling forms for molding, casting, and composites, Automated cutting, drilling, trimming.

Sindox 3DWOX 2X Manufacturer: Sindoh Model: 3DWOX 2X Specifications: Type: Dual Nozzle Fused Deposition Modeling (FDM); Nozzle Diameter: 0.4m; Max Build size (WxDxH): Applications: Dual material 3d printing, dissolvable support

Kniterate Digital Knitting Machine Manufacturer: Kniterate Model: Kniterate Specifications: Desktop 36", 7-gauge, 512-needle V-bed weft knitting machine. 6 yarn feeders with adjustable tension. Single-system, 3-way knit/tuck/miss technique: all needles individually controlled. Automatic transferring and splitting from both beds. Programmable racking, stitch size, and dual-roller fabric takedown. Stop motions for knots and yarn breakage. Top speed of 725mm/s. Applications: Clothing, footwear, functional fabrics, carpets, architecture, upholstery

Stratasys Object260 Connex3 Manufacturer: Stratasys Model: Objet260 Connex3 Specifications: SYSTEM SIZE AND WEIGHT 87 x 120 x 73.5 cm (34.2 x 47.2 x 29 in.); 264 kg (581 lbs.) Material Cabinet: 33 x 117 x 64 cm (13 x 46.1 x 25.2 in.); 76 kg (168 lbs.) BUILD SIZE 255 x 252 x 200 mm (10.0 x 9.9 x 7.9 in.) LAYER THICKNESS Horizontal build layers as fine as 16 microns (.0006 in.) ACCURACY Up to 200 microns for full model size (for rigid materials only, depending on geometry, build parameters and model orientation) BUILD RESOLUTION X-axis: 600 dpi; Y-axis: 600 dpi; Z-axis: 1600 dpi Applications: Very fine detail 3D printing with an assortment of materials- rigid, flexible, clear, opaque, bio-compatible, etc.. with the abilitiy to print more than one model material within a job, allowing for multi color parts and parts that have both rigid and flexible features

Roland Benchtop 4 Axis CNC Mill Manufacturer: Roland Model: MDX-540 Specifications: Loadable workpiece size 7.0 in. Diameter x 14.6 in. Length, positional accuracy +/-0.004 in./12 in., repeat accuracy +/-0.0019 in., spindle speed 12,000 rpm Applications: Precision 4-axis milling machine with a 4-tool automatic tool changer capable of cutting plastic, resin, wood and non-ferrous metals

Tuttnauer Brinkmann 2540E Autoclave Manufacturer: Tuttnauer Model: 2540E Specifications: Chamber Volume: 23 L; Reservoir Volume: 3 L; Max Pressure: 2.76 bar (40 psi); Sterilization temperature: 250 F (121 C) Applications: Sterilization of glass and polypropylene. Polyethylene will melt!

Juki DNU-1541-7 Single Needle Lockstitch Machine Manufacturer: Juki Model: DNU-1541-7 Specifications: 3,000sti/min, adjustible vertical stroke of the presser foot and walking foot, 9mm max stitch length, 36mm needle bar stroke, Horizontal-axis full-rotary double-capacity hook, automatic reverse feed Applications: Sewing

3D Systems Cubify Sense 3D Scanner Manufacturer: 3D Systems Model: Sense Cubify Specifications: Scan volume Min: 0.2m x 0.2m x 0.2m Max: 2m x 2m x 2m; Dimensions 5.08(w) x 7.08(h) x 1.3(d) inches 12.9(w) x 17.8(h) x 3.3(d) cm; Operating range Min: 0.2m Max: 1.6m; Depth image size 640(w) x 480(h) px; Color image size 1920(w) x 1080(h) px; Field of view Horizontal: 45 degrees Vertical: 57.5 degrees Diagonal: 69 degrees; Spatial x/y resolution @ 0.5m 0.9mm;Depth resolution @ 0.5m 1mm Applications: The Sense 3D scanner delivers accuracy close to 1 mm with resolution at 1 mm and an unprecedented color resolution of 1920 x 1080 for perfect color texture mapping. Sense has a generous scan range of between 7 and 72 inches to allow rapid 3D scanning of a wide range of objects.

NextEngine 3D Scanner Manufacturer: Nextengine Model: 2020i Specifications: SizeCompact 8.8" x 3.6" (letter size) desktop footprint. 10.9" high. Approximately 7 lbs. Applications: 3D scanning small to medium sized objects (think chess piece to basketball scale)

Formlabs Form 2 Manufacturer: Formlabs Model: Form 2 Specifications: Build Volume: 145x145x175 mm, Layer Thickness: 25–100 microns, Laser Spot Size: 140 microns, Laser Power: 250 mW, Automated Resin System, Self-heating Resin Tank, Auto generated supports, Machine size: 350mm (L) × 330mm (W) × 520mm (H) Applications: High resolution SLA 3D printing, investment casting

Stratasys Objet Eden 260VS Manufacturer: Stratasys Model: Objet Eden 260VS Specifications: Method: It works a bit like inkjet document printing, but instead of jetting drops of ink onto paper, the print head jets microscopic layers of liquid photopolymer onto a build tray and instantly cures them with UV light. Net Build size: 255 × 252 × 200 mm (10.0 x 9.9 x 7.9 in.) Applications: Very fine detail 3D printing with an assortment of materials- rigid, flexible, clear, opaque, bio-compatible, etc...

Omax 2652 Waterjet Cutter Manufacturer: Omax Model: Omax 2652 Specifications: X-Y Travel 52in. x 26in. (1321 mm x 660mm) Applications: Cuts complex flat parts out of most materials including metal, plastic, glass, ceramics and composites up to 6" thick directly from a CAD drawing or .DXF file.

VIVID 3D Scanner Manufacturer: Konica Minolta Model: VIVID 910 Specifications: Measuring method: Triangulation light block method, Scan Range (Depth of field): 0.6 to 2.5m (2m for WIDE), Laser Scan Method: Galvanometer-driven rotating mirror, Accuracy: TELE X: 0.22mm, Y: 0.16mm, Z: 0.10mm to the Z reference plane, X Direction Input Range: 111 to 463mm (TELE), 198 to 823mm (MIDDLE)359 to 1196mm (WIDE) Applications: Non-contact 3D scanning

Roland MDX-50 Manufacturer: Roland Model: MDX-50 Specifications: Operating range X:400mm Y:305mm Z:135mm, Feed rate XY: 7 to 3600mm/min Z: 7 to 3000 mm/min, Mechanical resolution 0.01 mm/step Spindle rotation speed 4500 - 15000 rpm Applications: Precision four-axis machining, including and machineable wax to make tooling for molding and casting and prototyping

Roland CAMMJet Pro 2 CJ-540 Plotter Manufacturer: Roland Model: CAMMJet Pro 2 CJ-540 Specifications: 54" width, Printing / Cutting width 185 to 1346 mm, Acceptable media widths 210 to 1371 mm, vinyl cutting knife, Piezo ink-jet. Dye based ink in black, cyan, magenta, yellow, light cyan, and light magenta. Max. 1440 dpi. Applications: Signs, pop-up cards, screen printing, flex circuits, antennas

FEI Strata DB-235 Focused Ion Beam Manufacturer: FEI Model: Strata DB-235 Specifications: dual beam SEM/FIB system combing a scanning electron microscope (SEM) with thermal emission tip for high resolution imaging and a focused ion beam (FIB) with gallium metal ion beam source for nanoscale cutting. High Resolution SEM image with resolution ~3 nm, Nanoscale cutting of structures using focused ion beam while simultaneously monitoring the progress using SEM, Applications: Electron microscopy, EDAX, Ion beam etching/deposition

Z-Corp Spectrum 510 Manufacturer: Z-Corp (now 3D Systems) Model: Spectrum 510 Specifications: Model material: ABSplus in ivory, white, black, red, olive green, nectarine, fluorescent yellow, blue or gray. Support material: Soluble Support Technology (SST) Build Size: 203 x 203 x 305 mm (8 x 8 x 12 in.) Applications: models with color, visualization

Beam Dynamics LMC10000 Laser Cutter Manufacturer: Beam Dynamics (now Coherent) Model: LMC10000 Specifications: 48"x48" cutting area, 12" vertical travel, 500W (1500W peak), .001" overall accuracy, 2000" in/min max cutting speed (3600" in/min max traverse speed), Automatic focus, Interlocked exhaust, water chiller and assist gas to protect machine and operators, Sealed beam path to protect optics and prevent vapor distortion of laser beam Applications: Cutting, marking, welding in metals, woods, plastics, fabrics, composites.

JEOL 200CX Transmission Electron Microscope Manufacturer: JEOL Model: 200CX Specifications: Guaranteed resolution: 0.14 nm lattice, 0.35 nm point to point; Accelerating voltage: 80, 100, 120, 160, 200 kV; Magnification: 6000 x - 120000 x. electron source is a tungsten filament (brightness = 2 x 109 A/m2 sr), which allows quick, convenient imaging from low magnification (100 times) to moderately high (330 000 times). It has four specimen holders including motorised double-tilt, non-motorised beryllium double tilt, two double-sample single-tilt holders and an Oxford Instruments double-tilt heating holder (up to 1000C). The camera uses negatives (50 plate capacity) for large field of view (FOV), high-density image capture. Applications: electron microscopy imaging (bright-field and dark-field) and diffraction (selected area and convergent beam)

Resonetics RapidX250L Excimer Laser Manufacturer: Resonetics Model: RapidX250L Specifications: 200mm x 200mm XY, 80 Watts at 248nm laser wavelength and 50 Watts at 193nm Applications: Resonetics RapidX250-L Series is an excimer laser-based laser micromachining system designed to fabricate micro-machined components as small as 1 micron feature size. The system can laser machine polymers, glass, sapphire, ruby, silicon, ceramics and metals among others.

Ultimaker 2+ 3D Printer Manufacturer: Ultimaker Model: 2+ Specifications: Build volume: 223 x 223 x 205 mm, Layer resolution: 0.80 mm nozzle: 600 to 20 micron, XYZ accuracy: 12.5, 12.5, 5 micron, Build speed: 0.80 mm nozzle: up to 24 mm3, Build plate: Heated glass build plate Applications: Prototyping

Sun Fire x2200 Computer Cluster Manufacturer: Sun (now Oracle) Model: Sun Fire x2200 Specifications: 25 dual quad-core Opterons Applications: Computationally intensive design, simulation, optimization, and inference

FEI XL30 Environmental Scanning Electron Microscope Manufacturer: FEI Model: XL30 Specifications: Resolution ~20nm, Schottky-emitter, automatic gun configuration control,optimized for the whole voltage range, 0.10 to 30 kV accelerating potential (focus compensated) and 1pA to 25 nA beam current, stable to better than 0.2% per hour. 50 mm x 50 mm X-Y travel, 360 degree rotation, -15 degree to 75 degree tilt (-15 degree to 45 degree for large specimens), compucentric rotation, 1 to 60 mm working distance, all five axes are under computer control Applications: electron microscopy, e-beam lithography

Anatech Plasma Bonder/Cleaner Manufacturer: Anatech Model: Anatech Specifications: Applications: oxygen plasma chamber to clean substrates and to bond polydimethylsiloxane (PDMS) and glass (borosilicate, fused silica)

Wire Bonder Manufacturer: WEST·BOND Inc. Model: 7476E – Wedge-Wedge Wire Bonder Specifications: three-axis micromanipulator; one bond tool head Applications: Bonds aluminum or gold wires ranging from 0.0007 in. to 0.002 in. with the wedge-wedge technique using ultrasonic energy to attach aluminum wire at room temperature and adding work piece heat for gold wire

APS L40 Pick and Place Manufacturer: Automated Production Systems Model: L40 Specifications: Placement rates up to 4800 cph, Placement accuracy to 0.001 in., Resolution of 0.0000787 in. (2 microns) and accuracy to 0.001 in. Accurately places virtually all SMT components including discretes, SOICs, PLCCs, QFPs, and BGAs, Interchangeable tape, tube, bulk or tray feeders Applications: Automated circuit board assembly
